Weights and Weight Sets
Action Engineers offers precision calibration of class F1, F2, M1 and M2 Our range of calibration is 1mg to 100kgAction Engineers is a NABL accredited calibration lab to certify your mass, volume & weight instruments. The calibration services are provided are by the highly experienced engineers. Our ISO 17025scope allows us to calibrate weights and weight set from class set E1, E2, F1,F2, M1, and M2 ranging from 1mg to 100kg. We also calibrate weight balance and weighing scales.
Our volumetric calibration capabilities range for pipette, flask, and beaker is from 10μl to 5000ml.
Our digitally enabled unique features:
On-site calibration is also offered by Action Engineers. We make sure the calibration services we provide at your location follow the same quality standards as followed by us at our calibration labs.
For more information, Request a Quote today!
| S.No | Discipline / Group | Measurand or Reference Material / Type of instrument or material to be calibrated or measured / Quantity Measured / Instrument | Calibration or Measurement Method or procedure | Measurement range and additional parameters where applicable (Range and Frequency) | Calibration and Measurement Capability(CMC) (±) |
| 1 | MECHANICAL VOLUME | Glass Pipette (Graduated / Non Graduated) Glass Burette | Using Digital Balance Up to 80/200 g, Readability 0.01/0.1 mg & Distilled Water of Known Density By Gravimetric Method | 1 ml to 100 ml | 10 µl |
| 2 | MECHANICAL VOLUME | Measuring Cylinder / Volumetric Flask / Conical Flask / Beaker |
Using Digital Balance Up to 1/5 kg, Readability 0.001/0.01 g & Distilled Water of Known Density By Gravimetric Method |
>100 ml to 1000 ml | 0.05 ml |
| 3 | MECHANICAL VOLUME | Measuring Cylinder / Volumetric Flask / Conical Flask / Beaker | Using Digital Balance Up to 5 kg, Readability 0.01 g & Distilled Water of Known Density By Gravimetric Method | >1000 ml to 5000 ml | 0.38 ml |
| 4 | MECHANICAL VOLUME | Measuring Cylinder / Volumetric Flask / Conical Flask / Beaker | Using Digital Balance Up to 80/200 g, Readability 0.01/0.1 mg & Distilled Water of Known Density By Gravimetric Method | 1 ml to 100 ml | 10 µl |
| 5 | MECHANICAL VOLUME | Micro-Pipette (Piston Type) | Using Digital Balance Up to 80/200 g, Readability 0.01/0.1 mg & Distilled Water of Known Density By Gravimetric Method | >100 μl to 5000 μl | 0.60 μl |
| 6 | MECHANICAL VOLUME | Micro-Pipette (Piston Type) | Using Digital Balance Up to 80/200 g, Readability 0.01/0.1 mg & Distilled Water of Known Density By Gravimetric Method | 10 µl to 100 µl | 0.20 µl |
| 7 | MECHANICAL VOLUME | Micro-Pipette (Piston Type) | Using Digital Balance Up to 80/200 g, Readability 0.01/0.1 mg & Distilled Water of Known Density By Gravimetric Method | >5 ml to 10 ml | 1 µl |
| 8 | MECHANICAL WEIGHTS | Weights Accuracy Class F1 & Coarser | Using Weights of Accuracy Class E2 & Digital Balance 80 g Readability 0.01 mg By ABBA Weighing Cycles As Per OIML R 111-1 | 1 g | 0.02 mg |
| 9 | MECHANICAL WEIGHTS | Weights Accuracy Class F1 & Coarser | Using Weights of Accuracy Class E2 & Digital Balance 80 g Readability 0.01 mg By ABBA Weighing Cycles As Per OIML R 111-1 | 10 g | 0.02 mg |
| 10 | MECHANICAL WEIGHTS | Weights Accuracy Class F1 & Coarser | Using Weights of Accuracy Class E2 & Digital Balance 200 g Readability 0.1 mg By ABBA Weighing Cycles As Per OIML R 111-1 | 100 g | 0.08 mg |
| 11 | MECHANICAL WEIGHTS | Weights Accuracy Class F1 & Coarser | Using Weights of Accuracy Class E2 & Digital Balance 80 g Readability 0.01 mg By ABBA Weighing Cycles As Per OIML R 111-1 | 100 mg | 0.02 mg |
| 12 | MECHANICAL WEIGHTS | Weights Accuracy Class F1 & Coarser | Using Weights of Accuracy Class E2 & Digital Balance 80 g Readability 0.01 mg By ABBA Weighing Cycles As Per OIML R 111-1 | 2 g | 0.02 mg |
| 13 | MECHANICAL WEIGHTS | Weights Accuracy Class F1 & Coarser | Using Weights of Accuracy Class E2 & Digital Balance 80 g Readability 0.01 mg By ABBA Weighing Cycles As Per OIML R 111-1 | 20 g | 0.02 mg |
| 14 | MECHANICAL WEIGHTS | Weights Accuracy Class F1 & Coarser | Using Weights of Accuracy Class E2 & Digital Balance 200 g Readability 0.1 mg By ABBA Weighing Cycles As Per OIML R 111-1 | 200 g | 0.11 mg |
| 15 | MECHANICAL WEIGHTS | Weights Accuracy Class F1 & Coarser | Using Weights of Accuracy Class E2 & Digital Balance 80 g Readability 0.01 mg By ABBA Weighing Cycles As Per OIML R 111-1 | 200 mg | 0.02 mg |
| 16 | MECHANICAL WEIGHTS | Weights Accuracy Class F1 & Coarser | Using Weights of Accuracy Class E2 & Digital Balance 80 g Readability 0.01 mg By ABBA Weighing Cycles As Per OIML R 111-1 | 5 g | 0.02 mg |
| 17 | MECHANICAL WEIGHTS | Weights Accuracy Class F1 & Coarser | Using Weights of Accuracy Class E2 & Digital Balance 80 g Readability 0.01 mg By ABBA Weighing Cycles As Per OIML R 111-1 | 50 mg | 0.01 mg |
| 18 | MECHANICAL WEIGHTS | Weights Accuracy Class F1 & Coarser | Using Weights of Accuracy Class E2 & Digital Balance 80 g Readability 0.01 mg By ABBA Weighing Cycles As Per OIML R 111-1 | 500 mg | 0.02 mg |
| 19 | MECHANICAL WEIGHTS | Weights Accuracy Class F2 & Coarser | Using Weights of Accuracy Class E2 & Digital Balance 1 kg Readability 0.001 g By ABBA Weighing Cycles As Per OIML R 111-1 | 1 kg | 1.33 mg |
| 20 | MECHANICAL WEIGHTS | Weights Accuracy Class F2 & Coarser | Using Weights of Accuracy Class E2 & Digital Balance 80 g Readability 0.01 mg By ABBA Weighing Cycles As Per OIML R 111-1 | 1 mg | 0.011 mg |
| 21 | MECHANICAL WEIGHTS | Weights Accuracy Class F2 & Coarser | Using Weights of Accuracy Class E2 & Digital Balance 80 g Readability 0.01 mg By ABBA Weighing Cycles As Per OIML R 111-1 | 10 mg | 0.011 mg |
| 22 | MECHANICAL ACCELERATION AND SPEED | Weights Accuracy Class F2 & Coarser | Using Weights of Accuracy Class E2 & Digital Balance 80 g Readability 0.01 mg By ABBA Weighing Cycles As Per OIML R111-1 | 2 mg | 0.011 mg |
| 23 | MECHANICAL WEIGHTS | Weights Accuracy Class F2 & Coarser | Using Weights of Accuracy Class E2 & Digital Balance 80 g Readability 0.01 mg By ABBA Weighing Cycles As Per OIML R 111-1 | 20 mg | 0.01 mg |
| 24 | MECHANICAL WEIGHTS | Weights Accuracy Class F2 & Coarser | Using Weights of Accuracy Class E2 & Digital Balance 5.2 kg Readability 0.01 g By ABBA Weighing Cycles As Per OIML R 111-1 | 5 kg | 11.6 mg |
| 25 | MECHANICAL WEIGHTS | Weights Accuracy Class F2 & Coarser | Using Weights of Accuracy Class E2 & Digital Balance 80 g Readability 0.01 mg By ABBA Weighing Cycles As Per OIML R 111-1 | 5 mg | 0.011 mg |
| 26 | MECHANICAL WEIGHTS | Weights Accuracy Class F2 & Coarser | Using Weights of Accuracy Class E2 & Digital Balance 80 g Readability 0.01 mg By ABBA Weighing Cycles As Per OIML R 111-1 | 50 g | 0.036 mg |
| 27 | MECHANICAL WEIGHTS | Weights Accuracy Class F2 & Coarser | Using Weights of Accuracy Class E2 & Digital Balance 1 kg Readability 0.001 g By ABBA Weighing Cycles As Per OIML R 111-1 | 500 g | 1 mg |
| 28 | MECHANICAL WEIGHTS | Weights Accuracy Class F2 & Coarser | Using Weights of Accuracy Class F1 & Digital Balance 20 kg Readability 0.1 g By ABBA Weighing Cycles As Per OIML R 111-1 | 10 kg | 112.81 mg |
| 29 | MECHANICAL WEIGHTS | Weights Accuracy Class F2 & Coarser | Using Weights of Accuracy Class E2 & Digital Balance 5.2 kg Readability 0.01 g By ABBA Weighing Cycles As Per OIML R 111-1 | 2 kg | 9.45 mg |
| 30 | MECHANICAL WEIGHTS | Weights Accuracy Class F2 & Coarser | Using Weights of Accuracy Class F1 & Digital Balance 20 kg Readability 0.1 g By ABBA Weighing Cycles As Per OIML R 111-1 | 20 kg | 128.63 mg |
